Fully D0-160 tested and weighing in at only 23 grams, MicroMax™ will help you comply with all the tightening and future regulations around operating small UAVs/MiniDrones and ensure SAFETY is included in your flight operations. Available in Red or White, the patented MicroMax™ provides a 360 degree arc of coverage. An amazing product from Aveo’s famous engineering prowess, which has made it the world market leader in UAV lighting by a wide margin.

12 High brightness LEDs for ANTICOLLISION light coverage (360°)

Packed with 12 ultra high brightness CREE LEDs in RED or WHITE color that are the industry state-of-the-art in performance and output lumens, the MicroMax feature a significantly lower footprint than competitor lights.

Low Profile/Small Diameter IR Strobe

An extremely lightweight, aerodynamic and low-profile design make this the light of choice for any aircraft requiring a rear coverage light due to wingtip light coverage zone limits.

Waterproof / Shockproof / Dust-proof

Specification

• Dimensions (mm): 35 mm x 11 mm
• Dimensions (inches): 1.378” x 0.433”
• Weight: 23 g / 0.81 oz
• Operating Voltage Range: 9 – 32 Vdc
• Output power (red): 6W (peak)
• Input current (red): 0.27A @28V (peak), 0.50A @14V (peak)
• Output power (white): 7.8W (peak)
• Input current (white): 0.35A @28V (peak)
• Repetition rate of strobe: 50 cycles per minute
• Ambient temperature: from -40°C to +85°C
• Overheat protection: Yes
• Recommended size of mounting screw: M3
• Reverse polarity protection: Yes
• Over-Voltage spike protection: 60V / 1s
• Under-Voltage protection: Yes, 8.5V
• Over-Voltage protection: Yes, 33V
• Waterproof, Dust-proof, Shock-proof, Vibration-proof: Yes
